Name: PVC Price Tag Holder Production Machine / Extruder / Plastic Machinery
Brand: Zhangjiagang Langbo Machinery Co. Ltd.
SKU: LB-32
Price: 25,000.00 USD
Availability: InStock

Características Galeria Descrição de produto Peça umas citações

Características

Especificações

Diâmetro do tubo: 75-250

Poder da extrusora: 55kW

Cor: Personalizado

Umbadores de tubo: Tubo duplo

Matéria-prima: PVC em pó e aditivos

Aplicação: Tubo de abastecimento de água

Tensão: 380V 50Hz ou personalizado

Grau automático: Total automaticamente

Projeto de parafuso: Parafuso e barril duplos

Serviço pós-venda prestado: Engenheiros disponíveis para máquinas de serviço no exterior, instalação de campo, comissionamento e

Garantia: 18 meses

Inversor: ABB

Cor: Personalizável

Matéria-prima: Pó de PVC

Motor: Marca Siemens

Contator: Siemens ou Schnider

Parafuso e barril: Extrusora de parafuso duplo cônico

Diâmetro do parafuso: 65/132

Aplicação de tubo: Fornecimento de água

Pacotes: Filme e caixas

Pagamento: T/T, L/C, Western Union

Prazo de entrega: 60 dias

Destacar:

PVC Price Tag Holder Extruder

PVC Price Tag Holder Machinery

Informação básica

Lugar de origem: Zhangjiagang, Jiangsu

Marca: LB

Certificação: CE ISO9001

Número do modelo: LB-32

Condições de Pagamento e Envio

Detalhes da embalagem: Pacote normal

Tempo de entrega: 30 dias úteis

Termos de pagamento: L/c, t/t

Habilidade da fonte: 15 conjuntos por mês

Galeria

PVC Price Tag Holder Production Machine / Extruder / Plastic Machinery

Descrição de produto

PVC Price Tag Holder Production Machine/Extruder/Plastic Machinery

Short description
The PVC profile production line is widely used for producing various PVC profiles, such as PVC window&door profile, PVC ceiling panel, PVC trunking. With drawing sections of the PVC profile, tailed solutions and mould will be made.

Processing Process
The process flow of this line is PVC powder + additive - mixing-material feeder-twin screw extruder- mould and calibrator-vacuum forming table-haul-off machine-cutting machine-discharge rack.

This PVC profile extrusion line adopts conical twin screw extruder, which is suitable for both PVC powder and PVC granules. It has degassing system to ensure the excellent material plasticization. The high speed mould is available, and it can largely increase the productivity.

Application
Suitable for supermarkets,convenience stores,chain stores,wholesale markets for fruit and food placement labels.The products have many varieties,bright transparency not easy to break,durable and other characteristics.

Specifications

Model	LB180	LB240	LB300	LB600
Max width of products(mm)	180	240	300	600
Screw Model	SJ55/110	SJ65/132	SJ65/132	SJ80/156
Motor power	22KW	37KW	37KW	55KW
Cooling Water(m3/h)	5	7	7	10
Compressor(m3/h)	0.2	0.3	0.3	0.4
Total length(m)	18m	22m	22m	25m

Delivery information:

1. Delivery: 30 days after ur order

2. Warrenty: 12 months

3. Payment: T/T 30% in advance, T/T 70% before delivery.

4. Packing: Standard export wooden case

Our Service

1. One year guarantee for whole machine.

2. 24 hours technical support.

3. Our engineers can provide installation & commission service overseas.

4. After a year, we can instruct you how to maintain the machine, and spare parts are provided with the best price.

5. We also can provide training service which help operators handle the machine well.

Single screw extruder machine:The extruder are crafted with top brand components to ensure production stability, efficiency and machine durability. Our extruder allocate international standard single screw and barrel. The screw has strong rigidity ensuring long service life and distinguished plasticizing effect.

Mould:The mould has spacious flow channel design to guarantee high extrusion capacity and good melting effect.

It is made and inspected by the experienced manufacturer. The optimized temperature control and flow channel design ensures precise melt temperature control.

Calibration table:The calibration table has stable steel frame and the whole body material is SUS 304 stainless steel. We have multi-dimension position adjustment system.

Haul-off Unit:The force distribution along each belts has sufficient hauling force. We offer good-quality bellt for the haul-off machine. The pneumatic pressure is conducive to the easy adjustment and product protection.

Cutter unit:Two kinds of cutting way including swarfless and saw cutting are available for customization.
